Model Code (Capacity)¹⁾

• MZ-V7S250 (250GB)
  MZ-V7S2T0 (2TB)

• MZ-V7S500 (500GB)

• MZ-V7S1T0 (1TB)

General Feature

• APPLICATION

  Client PCs

• FORM FACTOR²⁾

  M.2 (2280)

• INTERFACE

  PCIe^® Gen 3.0 x4, NVMe™ 1.3

• DIMENSION (WxHxD)

  Max. 80.15 x 22.15 x 2.38 (mm)

• WEIGHT

  Max 8.0 g

• STORAGE MEMORY

  Samsung V-NAND 3-bit MLC

• CONTROLLER

  Samsung In-house Controller

Special Feature

• TRIM SUPPORT

  Yes

• S.M.A.R.T SUPPORT

  Yes

• GC (GARBAGE COLLECTION)

  Auto Garbage Collection Algorithm

• ENCRYPTION SUPPORT

  AES 256-bit Encryption (Class 0), TCG/Opal, IEEE1667 (Encrypted drive)

• WWN SUPPORT

  Not Supported

• DEVICE SLEEP MODE SUPPORT

  Yes

Performance^3) 4)

• SEQUENTIAL READ

  Up to 3,500 MB/s

• SEQUENTIAL WRITE

  250GB: Up to 2,300 MB/s
  500GB: Up to 3,200 MB/s
  1TB: Up to 3,300 MB/s
  2TB: Up to 3,300 MB/s

• RANDOM READ (4KB, QD32)

  250GB: Up to 250,000 IOPS
  500GB: Up to 480,000 IOPS
  1TB: Up to 600,000 IOPS
  2TB: Up to 620,000 IOPS

• RANDOM WRITE (4KB, QD32)

  250GB: Up to 550,000 IOPS
  500GB: Up to 550,000 IOPS
  1TB: Up to 550,000 IOPS
  2TB: Up to 560,000 IOPS

• RANDOM READ (4KB, QD1)

  250GB: Up to 17,000 IOPS
  500GB: Up to 19,000 IOPS
  1TB: Up to 19,000 IOPS
  2TB: Up to 19,000 IOPS

• RANDOM WRITE (4KB, QD1)

  250GB: Up to 60,000 IOPS
  500GB: Up to 60,000 IOPS
  1TB: Up to 60,000 IOPS
  2TB: Up to 62,000 IOPS
